- Place of Origin: China
- Brand Name: Hebei Double Star
- Model Number: PLD800-PLD4800
1, feeding system: combined with storage hopper and feeding device together. The mainly function are storage materials and feeding the weigh bucket under the control system.
2, weighing system: it is the important part of the batching machine. Including weigh bucket, suspension device, weighing system sensor, batching control instrument, etc.
3, electrical control system: it is the heart parts of the batching machine, the function is that it can achieve every kinds of automatic batching process, and can achieve the weighing, display, operate of the batching machine. The system is mainly consist of batching control instrument and the electrical circuit together.
- Place of Origin: China
- Brand Name: Hebei Double Star
- Model Number: PLD800-PLD4800
Type | PLD800 | PLD1200Y | PLD1600QB | PLD2400-III(IV) |
Nominal volume of weigh bucket(m2) | 2*2 | 3*2 | 3*6 | 3*12 |
Productivity(m2/h) | 48 | 60 | 80 | 120 |
Aggregate size(mm | ≤60 | ≤60 | ≤60 | ≤60 |
Productivity(KW) | 20-25 | 30-45 | 50-60 | ≤90 |
Batching machine model | PLD800 | PLD1200 | PLD1600 | PLD2400 |
Power(kw) | 6.6 | 10.6 | 5.5 | 11 |
Batching precision | ±2% | ±2% | ±2% | ±2% |
Maximum weight value(kg) | 1500 | 2000 | 3000 | 4000 |
